1658690-1
Conn Housing Receptacle 15 POS DE Shell Size 2.28mm Crimp ST Cable Mount
Click image to enlarge
Manufacturer:TE Connectivity
Product Category:
Connectors, D-Shaped Connectors, Other D-Sub Connectors
Avnet Manufacturer Part #: 1658690-1
Secondary Manufacturer Part#: 1658690-1
-
RoHS 10 Compliant -
Tariff Charges
- Shell sizes offer wide choice of contact positions-9, 15, 25, 37 and 50
- Lower cost, commercial version of the military approved series
- Tin or zinc plated shells, with or without grounding indents
- Crimp snap-in contacts allows loading of only the number of contacts being used
- Available with shielding hardware and shielding enclosure kits
- Numerous cable clamps and mating hardware options
- Low cost, high performance, precisionformed crimp contacts
- Machine applied terminations assure highest production rates at lowest applied cost
- Intermateable with any size 20 Subminiature D connector dimensionally complying with MIL-C-24308
Technical Attributes
Find Similar Parts
| Description | Value | |
|---|---|---|
| Glass Filled Nylon|Carbon Steel | ||
| Straight | ||
| Receptacle | ||
| Cable Mount | ||
| 15 | ||
| 1 | ||
| -55 to 105 to 105 °C | ||
| 2.28 mm | ||
| 17.8 mm | ||
| 30.81 x 17.8 x 12.55 mm | ||
| 12.55 mm | ||
| 30.81 mm | ||
| 1658690 | ||
| DE | ||
| Crimp | ||
| Housing |
ECCN / UNSPSC / COO
| Description | Value |
|---|---|
| Country of Origin: | RECOVERY FEE |
| ECCN: | EAR99 |
| HTSN: | 8538908180 |
| Schedule B: | 8538907080 |
