TW9990AT-NA1-GR
Video Decoder IC, 10 bit, 4 Channels, 1.8 V to 3.3 V, QFN-32
Click image to enlarge
Manufacturer:Renesas Electronics
Product Category:
Processors, Video Encoders/Decoders
Avnet Manufacturer Part #: TW9990AT-NA1-GR
Secondary Manufacturer Part#: TW9990AT-NA1-GR
-
RoHS 10 Compliant -
Tariff Charges
- NTSC (M, 4.43) and PAL (B, D, G, H, I, M, N, N combination), PAL (60), SECAM support with automatic format detection
- Software selectable analog input control allows for combinations of single ended CVBS, differential CVBS, and S-Video
- Built-in analog anti-alias filter
- Two 10-bit ADCs and analog clamping circuit
- Fully programmable static gain or automatic gain control for the Y channel
- Programmable white peak control for the Y channel
- 4-H adaptive comb filter Y/C separation
- PAL delay line for color phase error correction
- Image enhancement with peaking and CTI.
- Digital sub-carrier PLL for accurate color decoding
- Digital Horizontal PLL for synchronization processing and pixel sampling
- Advanced synchronization processing and sync detection for handling non-standard and weak signal
- Programmable hue, brightness, saturation, contrast, and sharpness.
- Automatic color control and color
Technical Attributes
Find Similar Parts
| Description | Value | |
|---|---|---|
| WFQFN | ||
| Decoder | ||
| 32 |
ECCN / UNSPSC / COO
| Description | Value |
|---|---|
| Country of Origin: | PROJECTED FEE |
| ECCN: | EAR99 |
| HTSN: | 8542390090 |
| Schedule B: | 8542390060 |
Factory Lead Time:
