ICM7211AMIPLZ

ICM7211AMIPLZ is a 4-digit, LCD display driver. This device is configured to drive conventional LCD displays by providing a complete RC oscillator, divider chain, backplane driver, and 28-segment outputs. It also has a microprocessor-compatible input configuration, which provides data input latches and digit address latches under the control of high-speed chip select inputs. This device simplifies the task of implementing a cost-effective alphanumeric seven-segment display for microprocessor systems, without requiring extensive ROM or CPU time for decoding and display updating. The ICM7211AM provides the Code B output code, i. e, 0-9, dash, E, H, L, P, blank, but will correctly decode true BCD to seven-segment decimal outputs.

• Four digit non-multiplexed 7 segment LCD display outputs with backplane driver
• Complete onboard RC oscillator to generate backplane frequency
• Backplane input/output allows simple synchronization of server-devices to a host
• Code B display decoding, microprocessor input interfacing
• Direct drive display, 5V typ operating supply voltage
• 10µA operating current at (VDD = 5V ±10%, TA = 25°C, VSS = 0V)
• 19KHz typ oscillator frequency at (pin 36 floating, VDD = 5V ±10%, TA = 25°C, VSS = 0V)
• 15µs typ backplane rise/fall time at (CL = 5000pF)
• Temperature range from -40°C to 85°C
• 40-lead PDIP package
