600W Half-Bridge LLC Converter based on Infineon Solution
This evaluation board shows how to design a half-bridge LLC stage of a server SMPS with the target to meet 80+ Titanium standard efficiency requirements. For this purpose the following technologies have been used: 600V CoolMOS P7 SJ MOSFET technology (IPP60R180P7) on the primary side and OptiMOS 40V low voltage power MOSFET in SuperSO8 (BSC010N04LS) in the synchronous rectification secondary stage, in combination with QR CoolSET (ICE2QR2280Z), EiceDRIVER 2EDL hi-low side driver (2EDL05N06PF), EiceDRIVER 2EDN low side gate driver (2EDN7524F) and analog LLC controller (ICE2HS01G).
CATEGORY
Industrial,Data center,Power & charging
CREATED DATE:
Viewed times
Bookmark
PARTS IN DESIGN / BOM
| MFGR | PART# | BLK NM |
|---|
