MAL210217222E3
2200uF 450V 65x105 85°C 10000h
Click image to enlarge
Manufacturer:Vishay
Product Category:
Capacitors, Aluminum Electrolytic Capacitors, Snap-In/Screw Terminal Aluminum Electrolytic Capacitors
Avnet Manufacturer Part #: MAL210217222E3
Secondary Manufacturer Part#: MAL210217222E3
-
RoHS 10 Compliant -
Tariff Charges
MAL210217222E3 is a 102 PHR-ST series power high ripple current, screw terminal aluminum electrolytic capacitor. Typical applications include buffering and filtering, motor drives, inverters, UPS and traction systems and pulsed power supplies applications.
- 2200µF capacitance
- 450V rated voltage
- Polarized aluminum electrolytic capacitors, non-solid electrolyte
- Large types, cylindrical aluminum case, insulated with a blue sleeve
- Pressure relief in the sealing
- Low ESR
- Category temperature range -40°C to +85°C
- Endurance test at 85°C 2000h
- Shelf life at 0V, 85°C 500h
- Nominal case size Ø D x L: 65 x 105mm
Technical Attributes
Find Similar Parts
| Description | Value | |
|---|---|---|
| 2,200 µF | ||
| 20% | ||
| Screw | ||
| 0.055 O | ||
| 28.5 mm | ||
| 10000 hours @ 85°C | ||
| 85 °C | ||
| -40 °C | ||
| Polar | ||
| 65 mm | ||
| 105 mm | ||
| 10.1 A | ||
| 450 V |
ECCN / UNSPSC / COO
| Description | Value |
|---|---|
| Country of Origin: | RECOVERY FEE |
| ECCN: | EAR99 |
| HTSN: | 8532220085 |
| Schedule B: | 8532220085 |
Factory Lead Time:
