EB83-C6SGFW
Conn Card Edge SKT 12 POS 3.96mm Solder ST Thru-Hole
Click image to enlarge
Manufacturer:Vishay
Product Category:
Connectors, Card Edge Connectors
Avnet Manufacturer Part #: EB83-C6SGFW
Secondary Manufacturer Part#: EB83-S0C0640W
-
RoHS 10 Compliant -
Tariff Charges
- 0.156 C-C x 0.200" grid (3.96 mm x 5.08 mm)
- Greater design latitude 3 body materials: Diallyl phthalate, phenolic and glass-filled polyester, 6 contact termination styles, 8 body sizes, 7 mounting styles
- Bifurcated bellows contacts provide 2 flexing contact surfaces to assure positive contact
- Accepts PC board thickness of 0.054" to 0.071" (1.37 mm to 1.80 mm)
- Polarization between contact positions in all sizes
- Selective gold plating
Technical Attributes
Find Similar Parts
| Description | Value | |
|---|---|---|
| Polyester | ||
| Straight | ||
| Phosphor Bronze | ||
| Gold | ||
| Black | ||
| Gold | ||
| Through Hole | ||
| -55 to 125 °C | ||
| 3.9600 mm | ||
| 45.21 x 8.64 x 11.7 mm | ||
| 11.7 mm | ||
| Solder |
ECCN / UNSPSC / COO
| Description | Value |
|---|---|
| Country of Origin: | NO RECOVERY FEE |
| ECCN: | EAR99 |
| HTSN: | 8536694040 |
| Schedule B: | 8536694040 |
Ships
in 1 bus. day
