QPI-5LZ

The QPI-5 active EMI filter attenuates conducted common mode (CM) and differential-mode (DM) noise over the CISPR22 frequency range of 150 kHz to 30 MHz. The product is designed for use on 24 Vdc bus (10 – 40 Vdc) systems, with 100 Vdc surge capability. The QPI-5’s 14 A rating supports multiple DC-DC converter loads up to an ambient temperature of 65°C without de-rating. Designed for the telecom and ITE bus range, the QPI-5 supports the PICMG® 3.0 specification for filtering system boards to the EN55022 Class B limits.

In comparison to passive solutions, the use of active filtering reduces the volume of the common-mode choke, providing a low profile, surface mount device. Smaller size saves valuable board real estate and the reduced height enhances airflow in blade applications.

The QPI-5 is available as a lidded or an open-frame SiP (System-in-Package) with LGA mounting. Evaluation boards are available to allow for quick in-circuit testing of the QPI-5LZ within an existing system design.

• 60 dB CM attenuation at 250 KHz (50?)
• 75 dB DM attenuation at 250 KHz (50?)
• 40 Vdc (max input)
• 100 Vdc surge 100 ms
• 707 Vdc hipot hold off to shield plane
• 14 A rating
• 25.3 x 25.3 x 5.0 mm Lidded SiP (System-in-Package)
• 24.9 x 24.9 x 4.4 mm Open-frame SiP
• Low profile LGA package
• -40° to +125°C Ambient temperature
• Efficiency >99%
• Connect in series for higher attenuation
• TÜV Certified
