T92S7D12-24
General Purpose Relay, T92 Series, Power, Non Latching, DPST-NO, 24 VDC, 40 A
Click image to enlarge
Manufacturer:TE Connectivity
Product Category:
Electromechanical, Relays, Other Relays
Avnet Manufacturer Part #: T92S7D12-24
Secondary Manufacturer Part#: T92S7D12-24
-
RoHS 10 Compliant -
Tariff Charges
The T92S7D12-24 is a 2-pole general-purpose High Power PCB Relay with DC coil, T92 series. 2 form-C (2NO) contact configuration, AgCdO2 contact. Wash-tight, tape sealed, plastic case (mounting and termination code 1). Printed circuit board mount, printed circuit board terminals. Designed to control compressor loads to 3.5 tons, 110LRA/25.3FLA. Meets requirements of UL 508 and UL 873 spacings 8mm through air, 9.5mm over surface. Meets requirements of VDE 8mm spacing, 4kV dielectric coil-to contact. Meets requirements of UL Class F construction.
- RT III Environmental protection rating
Technical Attributes
Find Similar Parts
| Description | Value | |
|---|---|---|
| Silver Cadmium Oxide | ||
| 260 | ||
| Through Hole | ||
| -55 to 85 °C | ||
| 52.32 x 34.54 x 30.73 mm |
ECCN / UNSPSC / COO
| Description | Value |
|---|---|
| Country of Origin: | RECOVERY FEE |
| ECCN: | EAR99 |
| HTSN: | 8536410050 |
| Schedule B: | 8536410050 |
Factory Lead Time:
