280610-2
Pin Header, Single In Line, Wire-to-Board, 3.96 mm, 1 Rows, 4 Contacts, Through Hole, AMPMODU MOD I
Click image to enlarge
Manufacturer:TE Connectivity
Product Category:
Connectors, PC Board Connectors, Wire to Board Connectors
Avnet Manufacturer Part #: 280610-2
Secondary Manufacturer Part#: 280610-2
-
RoHS 10 Compliant -
Tariff Charges
The 280610-2 is a 4-position 1-row polarization Shrouded Header with brass contacts and green glass-filled polycarbonate housing.
- UL94V-0 Flammability
- 750V Dielectric withstanding voltage
Technical Attributes
Find Similar Parts
| Description | Value | |
|---|---|---|
| Polycarbonate | ||
| Straight | ||
| Brass | ||
| Gold Over Nickel | ||
| Header | ||
| Green | ||
| Tin Over Nickel | ||
| 265 | ||
| 15 mOhm | ||
| 3 A | ||
| Through Hole | ||
| 4 | ||
| 1 | ||
| -65 to 105 °C | ||
| 3.96 mm | ||
| 5.9 mm | ||
| 15.2 x 8.9 x 17 mm | ||
| 17 mm | ||
| 15.2 mm | ||
| 280610 | ||
| Solder | ||
| Partial Shrouded |
ECCN / UNSPSC / COO
| Description | Value |
|---|---|
| Country of Origin: | RECOVERY FEE |
| ECCN: | EAR99 |
| HTSN: | 8536694040 |
| Schedule B: | 8536694040 |
