102241-4
Conn Housing RCP 6 POS 2.54mm Crimp ST Cable Mount
Click image to enlarge
Manufacturer:TE Connectivity
Product Category:
Connectors, Discrete Housing Connectors
Avnet Manufacturer Part #: 102241-4
Secondary Manufacturer Part#: 90F4869
-
RoHS 10 Compliant -
Tariff Charges
The 102241-4 is a 6-way 1-row MOD IV Wire-to-board Receptacle Housing made of black nylon GF. The housing terminates 32 to 20AWG discrete wire and accepts a variety of receptacle and pin contacts.
- UL94V-0 Flammability rating
- 3A Contact current rating
- 250VAC Maximum voltage rating
- 12mO Termination resistance
- 750V Dielectric withstanding voltage
- 5000MO Insulation resistance
- -65 to 105°C Operating temperature range
Technical Attributes
Find Similar Parts
| Description | Value | |
|---|---|---|
| Nylon | ||
| Straight | ||
| Receptacle | ||
| Black | ||
| Cable Mount | ||
| -65 to 105 °C | ||
| 2.5400 mm | ||
| 15.24 mm | ||
| 15.24 x 15.24 x 4.62 mm | ||
| 4.62 mm | ||
| 15.24 mm | ||
| 32 to 20, 32 AWG |
ECCN / UNSPSC / COO
| Description | Value |
|---|---|
| Country of Origin: | RECOVERY FEE |
| ECCN: | EAR99 |
| HTSN: | 8538906000 |
| Schedule B: | 8538907080 |
Factory Lead Time:
