X9259UV24IZ

Name: X9259UV24IZ
Brand: Renesas Electronics
SKU: X9259UV24IZ
Availability: InStock

Click image to enlarge

Manufacturer:Renesas Electronics

Product Category: Data Conversion, Digital Potentiometers

Avnet Manufacturer Part #: X9259UV24IZ

Secondary Manufacturer Part#: X9259UV24IZ

RoHS 10 Compliant
Tariff Charges

Description

Technical Attributes

Find Similar Parts

	Description	Value
	IC Case / Package	TSSOP
	IC Mounting	Surface Mount
	No. of Pins	24
	No. of Pots	4
	No. of Steps	256
	Operating Temperature Max	85 °C
	Operating Temperature Min	-40 °C
	Resistance	50 kOhm

ECCN / UNSPSC / COO

Description	Value
Country of Origin:	NO RECOVERY FEE
ECCN:	EAR99
HTSN:	8542390050
Schedule B:	8542390060

In Stock : 0

Additional inventory

Factory Lead Time: 126 Weeks

Price for: Each

Quantity:

Min:248 Mult:62

USD $:

248+

$16.41429

496+

$15.52703
