ISL59837IAZ

The ISL59837 is a revolutionary device that allows true singlesupplyoperation of video amplifiers. Designed for systemsrequiring output swing below ground but lacking a negativepower supply, the ISL59837 generates the required negativerail internally from a +3.3V power supply. This allows forDC-accurate coupling of video onto a 75O double-terminatedline. The buffers have an integrated 6dB, eliminating the needfor external gain-setting resistors. An external referencevoltage can be applied to the REF pin to shift the analog videolevel down by the desired amount. The charge pump andamplifiers can be placed in a power down mode, consumingless than 1mA of current.

• Triple single-supply buffer
• Generates negative rail from from single +3.3V supply
• No output DC blocking capacitor needed
• 200MHz -3dB bandwidth
• 50MHz 0.1dB bandwidth
• Fixed gain of 2 output buffer
• Charge pump power down function (0.1mA typical)
• Outputs are high impedance in power-down mode
• Amplifier enable/disable function control
• Pb-free plus anneal available (RoHS compliant)
