ISL3158EIUZ-T
RS422/RS485 Transceiver, 1 Driver, 1 Receiver, 4.5V to 5.5V Supply, MSOP-8
Click image to enlarge
Manufacturer:Renesas Electronics
Product Category:
ICs, Serial Communications RS232, RS485, RS422
Avnet Manufacturer Part #: ISL3158EIUZ-T
- RoHS 10 Compliant
- Tariff Charges
- High Driver VOD 2.4V (Min) @ RD = 54O
- Better Noise Immunity, or Drive Up to 8 Terminations
- ±16.5kV IEC61000 ESD Protection on I/O Bus Pins
- High Transient Overvoltage Tolerance ±100V
- Full Fail-safe (Open, Short, Terminated) Receivers
- High Rx IOL for Opto-Couplers in Isolated Designs
- Hot Plug Circuitry - Tx and Rx Outputs Remain Three-State During Power-up/Power-down
- True 1/8 Unit Load for up to 256 Devices on the Bus
- High Data Rates up to 20 Mbps
- Low Quiescent Supply Current : 600µA
- Ultra Low Shutdown Supply Current : 70nA
Technical Attributes
Find Similar Parts
| Description | Value | |
|---|---|---|
| 8 Pins | ||
| 1 Transmitter | ||
| -40 °C | ||
| 1 Receiver | ||
| 4.5 V | ||
| 5.5 V | ||
| null | ||
| null | ||
| MSOP | ||
| 85 °C | ||
| null | ||
| 512 Nodes | ||
| null | ||
| Open, Short | ||
| 20 Kbps |
ECCN / UNSPSC / COO
| Description | Value |
|---|---|
| Country of Origin: | NO RECOVERY FEE |
| ECCN: | EAR99 |
| HTSN: | 8542390090 |
| Schedule B: | 8542390060 |
