ISL28134FHZ-T7A

Operational Amplifier, RRIO, 1 Channels, 3.5 MHz, 1.5 V/µs, 2.25V to 6V, ± 1.125V to ± 3V, SOT-23

Manufacturer:Renesas Electronics
Avnet Manufacturer Part #: ISL28134FHZ-T7A
Secondary Manufacturer Part#: ISL28134FHZ-T7A
  • Legend Information Icon RoHS 10 Compliant
  • Legend Information Icon Tariff Charges

The ISL28134 is a single, chopper-stabilized zero drift operational amplifier optimized for single and dual supply operation from 2.25V to 6.0V and ±1.125V and ±3.0V. The ISL28134 uses auto-correction circuitry to provide very low input offset voltage, drift and a reduction of the 1/f noise corner below 0.1Hz. The ISL28134 achieves ultra low offset voltage, offset temperature drift, wide gain bandwidth and rail-to-rail input/output swing while minimizing power consumption. The ISL28134 can be used over standard amplifiers with high stability across the industrial temperature range of -40°C to +85°C and the full industrial temperature range of -40°C to +125°C. The ISL28134 is available in an industry standard pinout SOIC and SOT-23 packages.

  • Rail-to-rail inputs and outputs
  • No 1/f noise corner down to 0.1Hz
  • Low offset voltage : 2.5µV, Max
  • Superb offset drift : 15nV/°C, Max
  • Single supply : 2.25V to 6.0V
  • Dual supply : ±1.125V to ±3.0V
  • Low ICC 675µA, typ
  • Wide bandwidth 3.5MHz

Technical Attributes

Find Similar Parts

Description Value
Matte Tin
260
0.0003@5V uA
2.5@5V mV
120 dB
Surface Mount
MSL 1 - Unlimited
1
0.9@5V mA
±3|6|1.125 V
-40 to 125 °C
5SOT-23
5
Single|Dual
2.9 x 1.6 x 1.14 mm
No
Rail to Rail Input/Output
Full-Range Industrial
SOT-23
2.25V to 6V, ± 1.125V to ± 3V
General Purpose Amplifier
3.5 MHz
1.5@5V V/us
174 dB

ECCN / UNSPSC / COO

Description Value
Country of Origin: RECOVERY FEE
ECCN: EAR99
HTSN: 8542330001
Schedule B: 8542330000
In Stock :  500
Ships in 1 bus. day
Additional inventory
Factory Lead Time: 84 Weeks
Price for: Each
Quantity:
Min:250  Mult:250
USD $:
1+
$2.755
100+
$2.698
