ISL22346UFV20Z-TK

Name: ISL22346UFV20Z-TK
Brand: Renesas Electronics
SKU: ISL22346UFV20Z-TK
Availability: InStock

Click image to enlarge

Manufacturer:Renesas Electronics

Product Category: Data Conversion, Digital Potentiometers

Avnet Manufacturer Part #: ISL22346UFV20Z-TK

Secondary Manufacturer Part#: ISL22346UFV20Z-TK

RoHS 10 Compliant
Tariff Charges

Description

Technical Attributes

Find Similar Parts

	Description	Value
	IC Case / Package	TSSOP
	IC Mounting	Surface Mount
	No. of Pins	20
	No. of Pots	4
	No. of Steps	128
	Operating Temperature Max	125 °C
	Operating Temperature Min	-40 °C
	Potentiometer Type	Non-Volatile
	Resistance	50 kOhm

ECCN / UNSPSC / COO

Description	Value
Country of Origin:	RECOVERY FEE
ECCN:	EAR99
HTSN:	8542390050
Schedule B:	8542390060

In Stock : 0

Additional inventory

Factory Lead Time: 126 Weeks

Price for: Each

Quantity:

Min:1000 Mult:1000

USD $:

1000+

$2.51429

2000+

$2.37838

4000+

$2.3336

6000+

$2.3217

8000+

$2.30979
