ISL2101AABZ-T

Name: ISL2101AABZ-T
Brand: Renesas Electronics
SKU: ISL2101AABZ-T
Availability: InStock

Click image to enlarge

Manufacturer:Renesas Electronics

Product Category: Power Management, Drivers & Controllers, Gate Drivers

Avnet Manufacturer Part #: ISL2101AABZ-T

Secondary Manufacturer Part#: ISL2101AABZ-T

Find Similar Parts

	Description	Value
	Bridge Type	Half Bridge
	Driver Configuration	Non-Inverting
	Driver Type	High and Low Side
	Input Delay	39 ns
	Input Logic Compatibility	TTL
	Lead Finish	Matte Tin
	Max Processing Temp	260
	Maximum Fall Time	600 ns
	Maximum Propagation Delay Time	50 ns
	Maximum Rise Time	600 ns
	Maximum Turn-Off Delay Time	6 ns
	Maximum Turn-On Delay Time	8 ns
	Mounting	Surface Mount
	MSL Level	MSL 1 - Unlimited
	No. of Channels	2
	No. of Pins	8
	Number of Drivers	2
	Number of Outputs	2
	Operating Temperature	-40 to 125 °C
	Operating Temperature Max	125 °C
	Operating Temperature Min	-40 °C
	Output Delay	31 ns
	Output Resistance	2.5 Ohm
	Package	8SOIC
	Peak Output Current	2 A
	Pin Count	8
	Power Switch Type	MOSFET
	Product Dimensions	5 x 4 x 1.5 mm
	Rad Hard	No
	Screening Level	Industrial
	Sink Current	2 A
	Source Current	2 A
	Supplier Package	SOIC
	Supply Voltage Max	14 V
	Supply Voltage Min	9 V

In Stock : 0

Additional inventory

Factory Lead Time: 182 Weeks

Price for: Each

Quantity:

Min:2500 Mult:2500

USD $:
