ICL7612DCPAZ
OP Amp Single GP ±8V/16V 8-Pin PDIP
Click image to enlarge
Manufacturer:Renesas Electronics
Product Category:
Amplifiers & Comparators, Operational Amplifiers
Avnet Manufacturer Part #: ICL7612DCPAZ
Secondary Manufacturer Part#: ICL7612DCPAZ
-
RoHS 10 Compliant -
Tariff Charges
The ICL761X series is a family of CMOS operational amplifiers. These devices provide the designer with high performance operation at low supply voltages and selectable quiescent currents, and are an ideal design tool when ultra low input current and low power dissipation are desired. The basic amplifier will operate at supply voltages ranging from ±1V to ±8V, and may be operated from a single Lithium cell. A unique quiescent current programming pin allows setting of standby current to 1mA, 100µA, or 10µA, with no external components. This results in power consumption as low as 20µW. The output swing ranges to within a few millivolts of the supply voltages.
- Wide Operating Voltage Range: ±1V to ±8V
- High Input Impedance 1012O
- Programmable Power Consumption : Low as 20µW
- Input Current Lower Than BIFETs : 1pA (Typ)
- Output Voltage Swing : V+ and V-
- Input Common Mode Voltage Range Greater Than Supply Rails (ICL7612)
- Pb-Free Plus Anneal Available (RoHS Compliant)
Technical Attributes
Find Similar Parts
| Description | Value | |
|---|---|---|
| Matte Tin | ||
| 0.00005@?5V uA | ||
| 60 dB | ||
| Through Hole | ||
| 1 | ||
| 2.5@±5V mA | ||
| ±8|16|±1|±3|±5 V | ||
| 0 to 70 °C | ||
| 8PDIP | ||
| 8 | ||
| Single|Dual | ||
| 10.16 x 7.11 x 4.95 mm | ||
| No | ||
| No | ||
| PDIP | ||
| ±1V to ±8V | ||
| General Purpose Amplifier | ||
| 1.4 MHz | ||
| 1.6@±5V V/us | ||
| 104 dB |
ECCN / UNSPSC / COO
| Description | Value |
|---|---|
| Country of Origin: | NO RECOVERY FEE |
| ECCN: | EAR99 |
| HTSN: | 8542330001 |
| Schedule B: | 8542330000 |
Factory Lead Time:
