HA2-5002-2ZR5254

The HA-5002 is a monolithic, wideband, high slew rate, high output current, buffer amplifier. The monolithic HA-5002 will replace the hybrid LH0002 with corresponding performance increases. These characteristics range from the 3000kO input impedance to the increased output voltage swing. Monolithic design technologies have allowed a more precise buffer to be developed with more than an order of magnitude smaller gain error. The HA-5002 will provide many present hybrid users with a higher degree of reliability and at the same time increase overall circuit performance.

• Voltage Gain : 0.995
• High Input Impedance : 3000k?
• Low Output Impedance : 3?
• Very High Slew Rate : 1300V/µs
• Wide Small Signal Bandwidth : 110MHz
• High Output Current : 200mA
• Pulsed Output Current : 400mA
• Monolithic Construction
• Pb-Free available (RoHS Compliant)
