A6DR-4100
Switch ON-OFF SPST 4 Piano 30VDC PC Pin Through Hole Box
Click image to enlarge
Manufacturer:Omron
Product Category:
Electromechanical, Switches, SIP/DIP Switches
Avnet Manufacturer Part #: A6DR-4100
Secondary Manufacturer Part#: A6DR4100BYOMZ
-
RoHS 10 Compliant -
Tariff Charges
The A6D series Sub-miniature DIP Switch offers space-saving and sealed, unsealed construction. The sealed construction equivalent to IEC 60529 prevents flux penetration and provides high contact reliability even in dusty locations and locations where water is used. Smooth, sure switching action enables comfortable operation. Designed to standards of DIL-IC top actuated types are auto insert-able. The gold-plated twin contacts and a slide-type, self-cleaning mechanism ensure high reliability.
- IP64 Protection rating
- 30mA at 30VDC Switching capacity
- 10µA at 3.5VDC Minimum permissible load
- 100MO Maximum contact resistance
- 10MO at 250VDC Minimum insulation resistance
- 500VAC Dielectric strength for 1 minute between terminals
- 30 to 500gf (0.3 to 4.9N) Operating force
- -20 to 70°C Ambient operating temperature
- 5000 Operations minimum mechanical service life
- 2000 Operations minimum electrical service life
Technical Attributes
Find Similar Parts
| Description | Value | |
|---|---|---|
| Piano | ||
| Gold | ||
| 260 | ||
| 30 mA | ||
| 30 V | ||
| 2000 Cycles | ||
| Through Hole | ||
| 4 | ||
| -20 to 70 to 70 °C | ||
| 8 | ||
| SPST | ||
| 12.2 x 10.75 x 6.4 mm | ||
| A6DR | ||
| DIP | ||
| ON-OFF | ||
| PC Pin |
ECCN / UNSPSC / COO
| Description | Value |
|---|---|
| Country of Origin: | RECOVERY FEE |
| ECCN: | EAR99 |
| HTSN: | 8536509065 |
| Schedule B: | 8536509065 |
Factory Lead Time:
