IRSM807-045MH

IRSM807-045MH is a 4A, 500V half-bridge module designed for advanced appliance motor drive applications such as energy efficient fans and pumps. IR's technology offers an extremely compact, high performance halfbridge topology in an isolated package. This advanced IPM offers a combination of IR's low RDS(on) Trench FREDFET technology and the industry benchmark half-bridge high voltage, rugged driver in a small PQFN package. At only 8x9mm and featuring integrated bootstrap functionality, the compact footprint of this surfacemount package makes it suitable for applications that are space-constrained. IRSM807-045MH functions without a heat sink.

• Integrated gate drivers and bootstrap functionality
• Suitable for sinusoidal or trapezoidal modulation
• Low RDS(on) Trench FREDFET
• Under-voltage lockout for both channels
• Matched propagation delay for all channels
• Optimized dV/dt for loss and EMI trade offs
• 3.3V input logic compatible
• Active high HIN and LIN
• Isolation 1500VRMS min
