HR30-6PA-6S(71)
Circular Connector, IP68, Circular Industrial, HR30 Series, Cable Mount Plug, 6 Contacts
-
RoHS 10 Compliant -
Tariff Charges
The HR30-6PA-6S(71) is a 6-position female miniature waterproof Circular Connector with black PPS/black PBT/natural polyacetal insulator, gold plated brass/phosphor bronze contacts and stainless steel spring. The HR30 series plug has straight connector orientation, soldering wire termination method and push-pull locking style. It is recommended for use with 26AWG wire. It features an easy to operate push/pull locks, proprietary clamping method allows clamping the cable by simply tightening the cord ring. Mating portions are polarized to avoid improper mating and connector damage. It features an white index mark on them which is used to quickly align the two interface for proper mating.
- Small-size with low profile
- Waterproof construction
- Push/pull lock
- Lightweight
- Clamp structure
- Easy mating operation
- Mis-insertion prevention
- Mating mark
- 3.9mm Cable outer diameter
- 2A Rated current
Technical Attributes
Find Similar Parts
| Description | Value | |
|---|---|---|
| Straight | ||
| Brass|Phosphor Bronze | ||
| Gold | ||
| 6Signal | ||
| Plug | ||
| Cable Mount | ||
| -25 to 85 °C | ||
| 12.6 mm | ||
| 29.8 mm | ||
| 29.8 mm | ||
| No | ||
| Solder |
ECCN / UNSPSC / COO
| Description | Value |
|---|---|
| Country of Origin: | RECOVERY FEE |
| ECCN: | EAR99 |
| HTSN: | 8536694020 |
| Schedule B: | 8536694020 |
