S24SP12005PDFA

The S24SP family, the highest power density (60W) industrial input range 2”X1” isolated power converter whose pinout follows industry standard. The S24SP series comes with a host of industry-standard features, such as over current protection, over voltage protection, over temperature protection and remote on/off. An optional heatsink is available for more extreme thermal requirements. All models have an ultra-wide 4:1 input voltage range (9V to 36V). With operating temperature of -40°C to +85°C, it is suitable for customers’ critical applications, such as process control and automation, transportation, data communication and telecom equipment, test equipment, medical device and everywhere where space on the PCB is critical.

• Efficiency up to 92.8%
• Wide input range, 9V-36V
• Package with Industry Standard Pinout
• Package Dimension:Without heat sink: 50.8 x25.4 x10.5mm (2.0” x1.0” x0.41”)With heat sink: 50.8 x25.4 x17.5mm (2.0” x1.0” x0.69”)
• Over voltage protection, hiccup mode
• Over current protection, hiccup mode
• Positive or Negative Remote ON/OFF
• Without tantalum capacitor inside module
• Operating Temperature range - 40°C to +85°C
• Input to Output Isolation: 1500VDC
• RoHS Compliant
• 3 Years Product Warranty
• Heat-sink is option
• UL60950, 2nd Edition, (Approval pending)
