HSMF-C153
LED, Red, Yellow, SMD, 2mm x 2.7mm, 170 °, Rectangular, R 20mA, Y 20mA
Manufacturer:Broadcom
Product Category:
Optoelectronics, LEDs & Lighting, LEDs
Avnet Manufacturer Part #: HSMF-C153
Secondary Manufacturer Part#: HSMF-C153
-
RoHS 10 Compliant -
Tariff Charges
The HSMF-C15x series of bicolor chip-type LEDs is designed in an industry standard package for ease of handling and use. These bicolor LEDs are available as high efficiency red/yellow, high efficiency red/green, yellow/ green, orange/green and green/amber. The HSMF-C15x has the widely used 3.2 x 2.7 mm footprint and wide viewing angle make this LED exceptional for backlighting applications. All packages are compatible with reflow solder processes. The small size and wide viewing angle make these LEDs prime choices for backlighting applications and front panel indicators especially where space is a premium.
- Small size
- Industry standard footprint
- Compatible with IR solder
- Diffused optics
- Operating temperature range of –40°C to +85°C
- Color: GaP Yellow / GaP HER
- Available in 8 mm tape on 7 in. (178 mm) diameter reels
Technical Attributes
Find Similar Parts
| Description | Value | |
|---|---|---|
| Red/Yellow | ||
| 626/586 nm | ||
| 10|8 mcd | ||
| Gold | ||
| GaP | ||
| 2x2.7x0.6 mm | ||
| Rectangular | ||
| 260 | ||
| 20 mA | ||
| 2.6 V | ||
| 65 mW | ||
| Surface Mount | ||
| Top Mount | ||
| MSL 2A - 4 weeks | ||
| -40 to 85 °C | ||
| 4Chip LED | ||
| 630, 589 nm | ||
| 4 | ||
| 2.7 x 3.2 x 1.1 mm | ||
| 5 V | ||
| Bi-Color | ||
| 170 ° |
ECCN / UNSPSC / COO
| Description | Value |
|---|---|
| Country of Origin: | RECOVERY FEE |
| ECCN: | EAR99 |
| HTSN: | 8541410000 |
| Schedule B: | 8541410000 |
