HDSM-281C
Displays Segmented Module 1DIGIT 9LED Red CA 11-Pin SMD T/R
Click image to enlarge
Manufacturer:Broadcom
Product Category:
Displays, LED Displays, Segment LED Displays
Avnet Manufacturer Part #: HDSM-281C
Secondary Manufacturer Part#: HDSM-281C
-
RoHS 10 Compliant -
Tariff Charges
The HDSM-281C is a single digit display of 0.28” (7.0mm) height. This device utilizes AlInGaP / GaAs chips and has a grey top surface with white segments.
- 0.28” digit height
- Low current operation
- Excellent characters appearance
- Available in CA and CC
- 1000 pieces per reel
- Moisture sensitivity level: Level 3
- RoHS compliant
- Color: Red
Technical Attributes
Find Similar Parts
| Description | Value | |
|---|---|---|
| 624 nm | ||
| 7500 ucd | ||
| Matte Tin | ||
| 260 | ||
| 25 mA | ||
| Surface Mount | ||
| MSL 3 - 168 hours | ||
| -40 to 105 °C | ||
| 11SMD | ||
| 632 nm | ||
| 11 | ||
| 7.5 x 10.8 x 3.75 mm | ||
| SMD | ||
| 3.15 mm | ||
| 7 mm | ||
| 4.6 mm |
ECCN / UNSPSC / COO
| Description | Value |
|---|---|
| Country of Origin: | RECOVERY FEE |
| ECCN: | EAR99 |
| HTSN: | 8541410000 |
| Schedule B: | 8541410000 |
Factory Lead Time:
