SRR1050A-470Y
Power Inductor (SMD), 47 uH, ± 30%, 2 A, Shielded, 2 A, 10.2mm x 10mm x 4.8mm
Click image to enlarge
Manufacturer:Bourns
Product Category:
Inductors, Power Inductors, SMD Power Inductors
Avnet Manufacturer Part #: SRR1050A-470Y
Secondary Manufacturer Part#: SRR1050A-470Y
-
RoHS 10 Compliant -
Tariff Charges
The SRR1050A-470Y from Bourns is a SRR1050A series SMD shielded power inductor. It is typically used in applications such as driver assistant, infotainment, lighting, DC to DC converters, power supplies.
- Automotive grade AEC-Q200 qualified
- Inductance is 47µH at 1MHz/1V
- Tolerance is ±30%
- DCR (DC resistance of inductor) is 0.094mohm (±20%)
- Maximum RMS current (Irms) is 2A
- Maximum saturation current (Isat) is 2A
- Ferrite core, enamelled copper wire and Sn terminal finish
- Operating temperature range from -40°C to 125°C
- Dimension is 10.2mm x 10mm x 4.8mm
Technical Attributes
Find Similar Parts
| Description | Value | |
|---|---|---|
| Ferrite | ||
| 0.127 Ohm | ||
| 47 uH | ||
| 30 | ||
| Shielded | ||
| 4.8 mm | ||
| 10.2 mm | ||
| SRR1050A Series | ||
| 10 mm | ||
| 2 A | ||
| 2 A |
ECCN / UNSPSC / COO
| Description | Value |
|---|---|
| Country of Origin: | RECOVERY FEE |
| ECCN: | EAR99 |
| HTSN: | 8504504000 |
| Schedule B: | 8504500000 |
Factory Lead Time:
