SRP5030TA-6R8M
Power Inductor (SMD), 6.8 µH, 4 A, Shielded, 4.3 A, SRP5030TA Series
Click image to enlarge
Manufacturer:Bourns
Product Category:
Inductors, Power Inductors, SMD Power Inductors
Avnet Manufacturer Part #: SRP5030TA-6R8M
Secondary Manufacturer Part#: 33AK4479
-
RoHS 10 Compliant -
Tariff Charges
The SRP5030TA series from Bourns are automotive grade wire wound shielded SMD power inductors.
- Automotive grade AEC-Q200 qualified
- Dimension of 5.7mm (L) x 5.2mm (W) x 2.8mm (H)
- Inductance value range from 0.33µH to 10µH
- Current value (Irms) range from 2.75A to 14A
- Saturation current range from 3.5A to 18A
- DCR value range from 4.3mohm to 128mohm
- Carbonyl powder core, enamelled copper wire
- Tin(Sn) finish terminal
- High saturation current
- Operating temperature range from -40°C to 150°C
Technical Attributes
Find Similar Parts
| Description | Value | |
|---|---|---|
| Carbonyl Powder | ||
| 0.0762 Ohm | ||
| 6.8 uH | ||
| ±20% | ||
| 2121 | ||
| Shielded | ||
| 2.8 mm | ||
| 5.7 mm | ||
| SRP5030TA Series | ||
| 5.2 mm | ||
| 4 A | ||
| 4.3 A |
ECCN / UNSPSC / COO
| Description | Value |
|---|---|
| Country of Origin: | RECOVERY FEE |
| ECCN: | EAR99 |
| HTSN: | 8504504000 |
| Schedule B: | 8504500000 |
Factory Lead Time:
