DR331-513AE
Choke, Data Line, Surface Mount, 51 µH, DR331 Series, 500 mA, 7.3mm x 5.4mm x 4.7mm
Click image to enlarge
Manufacturer:Bourns
Product Category:
Inductors, SMD Common Mode Chokes
Avnet Manufacturer Part #: DR331-513AE
Secondary Manufacturer Part#: DR331-513AE
-
RoHS 10 Compliant -
Tariff Charges
The DR331-513AE from Bourns is a DR331 series surface mount data line choke. It has wide frequency range over 1000MHz. The choke features open construction is more economical than DR332 series applications. It is used for the suppression of EMI in data and signal lines (example CAN bus).
- 51µH ±25% L (1-4) at 100KHz, 0.1Vrms
- 2µH LL (1-4) at 100KHz, 0.1Vrms (typ) (2-3 short)
- 0.30 ohm maximum RDC (winding)
- 0.5A maximum rated current
- Sector winding, 260°C (10sec) resistance to solder heat
- Rated voltage is 80VDC/42VAC
- Operating temperature range from -40°C to +135°C
- 250VAC/60Hz, 3mA hipot (1sec)
- Ferrite core, enamelled copper wire (class F) wire, phenolic (UL 94V-0) base
- Cu/Ni/Sn terminal, epoxy resin adhesive
Technical Attributes
Find Similar Parts
| Description | Value | |
|---|---|---|
| 500 mA | ||
| 51 uH | ||
| 4.7 mm | ||
| 7.3 mm | ||
| DR331 Series | ||
| 5.4 mm |
ECCN / UNSPSC / COO
| Description | Value |
|---|---|
| Country of Origin: | RECOVERY FEE |
| ECCN: | EAR99 |
| HTSN: | 8504504000 |
| Schedule B: | 8504500000 |
