108-0901-001
Banana Test Connector, Jack, Panel Mount, 15 A, 7 kV, Tin Plated Contacts, White
Click image to enlarge
Manufacturer:BEL
Product Category:
Connectors, Lab/Test Connectors, Banana Connectors
Avnet Manufacturer Part #: 108-0901-001
Secondary Manufacturer Part#: 108-0901-001
-
RoHS 10 Compliant -
Tariff Charges
The 108-0901-001 is a red Banana Jack with insulated solder terminal. It fits for 0.175-inch standard banana plug.
- Keyed mounting with double flats
- Accepts up to 16 gauge wire
- Nylon UL approved for self extinguishing
- 0.010Ω contact resistance (maximum)
- 2.4pF contact-to-panel
Technical Attributes
Find Similar Parts
| Description | Value | |
|---|---|---|
| Nylon 66 | ||
| Straight | ||
| Brass | ||
| Bright Tin | ||
| Receptacle | ||
| Panel Mount | ||
| 11.13 mm | ||
| 23.83 mm | ||
| 23.83 mm | ||
| Solder |
ECCN / UNSPSC / COO
| Description | Value |
|---|---|
| Country of Origin: | NO RECOVERY FEE |
| ECCN: | EAR99 |
| HTSN: | 8536904000 |
| Schedule B: | 8536904000 |
