AME15-12SMAZ
AC/DC Power Supply Single-OUT 12V 1.25A 15W 4
Click image to enlarge
Manufacturer:Aimtec
Product Category:
Power Supplies, AC / DC Converters, AC / DC PCB Mount Power Supplies
Avnet Manufacturer Part #: AME15-12SMAZ
Secondary Manufacturer Part#: AME15-12SMAZ
-
RoHS 10 Compliant -
Tariff Charges
AME15-12SMAZ is an AME15-MAZ series 15W AC-DC / DC-DC converter. It features 4000VAC I/O isolation, soft start, energy star compliant. It includes over load, over voltage, short circuit protection. Certified by cULus.
- Input voltage range from 90 to 264VAC, 47 to 440Hz, 130 to 370VDC
- Output voltage is 12V, maximum output current is 1.25A
- Efficiency is 78%(115VAC), 79%(230VAC)
- Typical switching frequency is 132KHz
- Plastic (flammability to UL 94V-0) case material
- Operating temperature range from -40°C to +85°C
- Dimensions (L x W x H) is 2.56 x 1.83 x 0.83inch
Technical Attributes
Find Similar Parts
| Description | Value | |
|---|---|---|
| 90V AC to 264V AC | ||
| 1 | ||
| -40 to 85 °C | ||
| 1.25 A | ||
| 1.25 A | ||
| 15 W | ||
| 12 V | ||
| 12 V | ||
| Fixed | ||
| 65 mm | ||
| 21 mm | ||
| 46.5 mm |
ECCN / UNSPSC / COO
| Description | Value |
|---|---|
| Country of Origin: | RECOVERY FEE |
| ECCN: | EAR99 |
| HTSN: | 8504409510 |
| Schedule B: | 8504409510 |
Factory Lead Time:
