AM5TW-2403S-RZ
Isolated Through Hole DC/DC Converter, Household & ITE, 4:1, 5 W, 1 Output, Fixed, 3.3 V, 1.3 A, Regulated, DIP
Click image to enlarge
Manufacturer:Aimtec
Product Category:
Power Supplies, DC / DC Converters, Isolated Through Hole DC / DC Converters
Avnet Manufacturer Part #: AM5TW-2403S-RZ
Secondary Manufacturer Part#: AM5TW-2403S-RZ
-
RoHS 10 Compliant -
Tariff Charges
- AM5TW-RZ series 5W DC to DC converter
- Input voltage range from 9 to 36V, output voltage is 3.3V
- Maximum output current is 1300mA, isolation is 1500VDC, efficiency is 75%
- 24 pin DIP package, wide 4:1 input range
- Pin compatible with multiple manufacturers, continuous short circuit protection
- Typical switching frequency is 266KHz (100% load)
- Nickel-coated copper case material
- Operating temperature range from -40°C to +85°C
- Certified by designed to meet IEC/EN/UL60950-1, 62368-1
- Dimensions (L x W x H) is 31.75 x 20.32 x 10.16mm
Technical Attributes
Find Similar Parts
| Description | Value |
|---|
ECCN / UNSPSC / COO
| Description | Value |
|---|---|
| Country of Origin: | RECOVERY FEE |
| ECCN: | EAR99 |
| HTSN: | 8504409580 |
| Schedule B: | 8504409585 |
