制造商:
Vishay
产品分类:
电阻器,
表面贴装电流检测电阻器
WSL2512R0500FEA
电流感应电阻器, 表面安装, 0.05 ohm, 1 W, 2512 [6432公制], ± 1%, WSL 系列
安富利制造商模型#:
WSL2512R0500FEA
RoHS 10 Compliant
The WSL2512R0500FEA is a 0.05Ω 1W SMD low value Current Sense Resistor with solid metal nickel-chrome resistive element. The power resistor features silicone coating with ink print, proprietary processing technique produces extremely low resistance values and construction is impervious against high sulphur environments.
技术参数
- Very low inductance of 0.5 to 5nH
- Low thermal EMF (3μV/°C)
- -65 to 170°C Operating temperature range
技术特性
查找类似的料号|
|
描述 | 值 |
|---|---|---|
|
|
电阻 | 50 MOhm |
|
|
资质 | AEC-Q200 |
|
|
耐受性 | 1 |
|
|
电阻技术 | Metal Strip |
|
|
温度系数 | 75.0000 ppm/°C |
|
|
产品宽度 | 3.18 mm |
|
|
最低工作温度 | -65 °C |
|
|
产品范围 | WSL Series |
|
|
最高工作温度 | 170 °C |
|
|
电阻器外壳/封装 | 2512 |
|
|
额定功率 | 1.0000 W |
|
|
电阻器类型 | Power |
|
|
产品长度 | 6.35 mm |
ECCN / UNSPSC
| 描述 | 值 |
|---|---|
| ECCN: | EAR99 |
| 计划交货期 B: | PARTS... |
| HTSN: | PARTS... |
文档
您需要登录才能查看内容
文档
| 标题 | 下载 | 类别 | 发布日期 |
|---|---|---|---|
| WSL and WSL-18 (High Power) Short Time Overload (STOL) Rating will be removed from the datasheet. | Errata-Sheets | 20200205 |
