61794-1

环形舌片端子, M4, #8, 14 AWG, 2 mm², 非绝缘

61794-1 | 环形端子 | TE Connectivity
TE Connectivity
制造商: TE Connectivity
安富利制造商模型#: 61794-1
RoHS 10 Compliant

The 61794-1 is a Ring Tongue Terminal made of steel with tin plated finish. This straight open barrel terminal features crimp termination and accepts 18 to 14AWG wire.

技术参数

  • Reproducible crimping results
  • High quality
  • Reduced manufacturing costs
  • No soldering required
  • Type : F
  • Wire Range AWG - mm2 : 18 - 14, 0.8 - 2.0
  • Insulation Diameter : .105 - .145, 2.67 - 3.68
  • Stud Size : 8
  • Thickness : .025, 0.64
  • Material : Brass
  • Proven crimp technology
  • Large range of product configurations
  • Excellent mechanical and electrical performance
  • Recognized under the Component Recognition Program of Underwriters Laboratories Inc.
  • Certified by Canadian Standards Association

技术特性

查找类似的料号
描述
主体材料 Steel
铅完成 Tin
产品尺寸 19.61 x 9.4 mm
类型 Star Ring Tongue Terminal
Wire Size 18 to 14, 18 AWG
Plating Tin
产品长度 19.61 mm
Stud Size 4.17 mm

ECCN / UNSPSC

描述
ECCN: EAR99
计划交货期 B: PARTS...
HTSN: PARTS...
