制造商:
Panasonic
35SVPF120M
Aluminum Polymer Capacitor, 120 uF, 35 V, ± 20%, Radial Can - SMD, Surface Mount
安富利制造商模型#:
35SVPF120M
RoHS 6 Compliant
35SVPF120M is an OS-CON™ SVPF series conductive polymer aluminium solid capacitor. This SMD capacitor utilizes aluminium and a high-conductivity polymer material to offer low ESR, excellent noise reduction and ripple current capabilities. The capacitor is characterized by a long life span and minimal changes in ESR throughout the entire rated temperature range.
技术参数
- Capacitance is 120µF with ±20% tolerance
- 0.018ohm ESR
- 5000 hours at 105°C endurance
- Operating temperature range from -55°C to 105°C
- 4.4A ripple current
- Voltage(DC) is 35V
- 12.6mm x 10mm product height x product diameter
- Radial CAN and solder terminals
- Highly stable temperature characteristics and long lifetime at high temperatures
- Can be used widely in industrial applications
技术特性
查找类似的料号|
|
描述 | 值 |
|---|---|---|
|
|
纹波电流 | 4400 A |
|
|
电容器安装 | Surface Mount |
|
|
最高工作温度 | 105 °C |
|
|
产品直径 | 10 mm |
|
|
寿命@温度 | 5000 hours @ 105°C |
|
|
产品宽度 | 10 X 12.6 |
|
|
最低工作温度 | -55 °C |
|
|
电容器外壳/封装 | Radial Can - SMD |
|
|
电容器端子 | Solder |
|
|
ESR | 18 mOhm |
|
|
电容容差 | 20% |
|
|
电容 | 120 uF |
|
|
电压(DC) | 35 V |
ECCN / UNSPSC
| 描述 | 值 |
|---|---|
| ECCN: | EAR99 |
| 计划交货期 B: | 85322200 |
| HTSN: | 85322200 |
