制造商:
onsemi
FUSB340TMX
SuperSpeed Switch, USB 3.1, 1.5 V to 5 V, 18 Pins, X2QFN
安富利制造商模型#:
FUSB340TMX
RoHS 10 Compliant
FUSB340TMX is a USB 3.1 SuperSpeed 10Gbps switch. It is a 2:1 data switch for USB SuperSpeed Gen1 and Gen2, 5 Gbps and 10 Gbps data. It is targeted at the mobile device market and for use in Type-C applications where a reversible cable requires a switch. The FUSB340 data switch offers superior performance in various high-speed data transmission protocols USB 3.1 SuperSpeed (Gen 2), 10 Gbps, PCI Express, Gen 3, SATA, fibre channel, and display port 1.3. Applications include smartphones, tablets, and notebooks.
技术参数
- Differential, -3dB bandwidth is 10GHz typ (VIN = 1Vpk-pk, RL = 50 ohm, CL = 0pF, TA = -40 to +85°C)
- USB 3.1 SuperSpeed 5Gbps and10Gbps Switch
- Differential insertion loss is -1.0dB typ (VIN=0dBm, f=2.5GHz, RL = 50 ohm, CL = 0pF, TA = -40-85°C)
- Quiescent supply current is 12µA typ (active low VOE = 0, VSEL = 0 or VDD, IOUT = 0, -40 to +85°C)
- Low shutdown power of <1µA maximum
- 2KV HBM ESD protection
- Wide VDD operating range from 1.5V to 5.0V
- Quiescent supply current is 12µA typ (active low VOE = 0, VSEL = 0 or VDD, IOUT = 0, TA = 25°C)
- Power supply slew rate range from 100 to 1000µs/V
- 18 lead TMLP package, operating temperature range from -40 to +85°C
技术特性
查找类似的料号|
|
描述 | 值 |
|---|---|---|
|
|
通道数 | 4 |
|
|
集成电路外壳/封装 | X2QFN |
|
|
最低工作温度 | -40 |
|
|
引脚数 | 18 |
|
|
最高工作温度 | 85 |
ECCN / UNSPSC
| 描述 | 值 |
|---|---|
| ECCN: | EAR99 |
| 计划交货期 B: | 8542310000 |
| HTSN: | 8542390001 |
文档
您需要登录才能查看内容
文档
| 标题 | 下载 | 类别 | 发布日期 |
|---|---|---|---|
| FUSB340TMX 18LD,TMLP,QUAD,2.0X2.8MM BODY, .375MM THICK, 0.4MM PITCH, TIED DAP | Part-Block-Diagram | 20150901 |
