製造商:
TE Connectivity
521781-1
Conn Housing RCP 4 POS 6.81mm Crimp ST Loose Piece
替代料號:
521781-1
RoHS 10 Compliant
Four and five position connectors designed to mate to power and discrete speed tap control contacts on high efficiency residential HVAC blower motors
Designed using TE Connectivity’s Mark III Positive Lock Connection System
Ergonomically friendly, one piece housing design
技術參數
- Housing : 4 position
- Ergonomically friendly, one piece housing designs
- Low mating force
- Positive locking to mating tabs
- Audible click upon mating
- Housings keyed to ensure proper position and orientation at mating
- Housings made from UL 94 V-0 Flammability Rated Material
技術屬性
查找類似的料號|
|
描述 | 值 |
|---|---|---|
|
|
極性 | Receptacle |
|
|
Housing Color | Natural |
|
|
Body Orientation | Straight |
|
|
Base/Housing Material | Nylon 66 |
|
|
Pitch | 6.8100 mm |
|
|
類型 | Housing |
|
|
產品長度 | 41.75 mm |
|
|
產品尺寸 | 41.75 x 10.16 mm |
|
|
Number of Contacts | 4 POS |
|
|
Number of Rows | 1 |
ECCN/UNSPSC
| 描述 | 值 |
|---|---|
| ECCN: | EAR99 |
| 計劃交貨期 B: | PARTS... |
| HTSN: | PARTS... |
