製造商:
Panasonic
EEE1HA101UP
SMD Aluminium Electrolytic Capacitor, Radial Can - SMD, 100 µF, 50 V, 2000 hours @ 85°C, Polar
替代料號:
EEE1HA101UP
RoHS 10 Compliant
S series V Type aluminium electrolytic capacitors are characterized by their endurance of 85°C 2000h.
技術參數
- AEC-Q200 qualified
- Temperature range from -40°C to +85°C
技術屬性
查找類似的料號|
|
描述 | 值 |
|---|---|---|
|
|
電壓(DC) | 50 V |
|
|
電容 | 100 uF |
|
|
電容容差 | 20% |
|
|
電容器端子 | Solder |
|
|
紋波電流 | 200 mA |
|
|
產品直徑 | 8 mm |
|
|
最高工作溫度 | 85 °C |
|
|
壽命@溫度 | 2000 hours @ 85°C |
|
|
極性 | Polar |
|
|
產品寬度 | 8 x 10.2 |
|
|
最低工作溫度 | -40 °C |
ECCN/UNSPSC
| 描述 | 值 |
|---|---|
| ECCN: | EAR99 |
| 計劃交貨期 B: | PARTS... |
| HTSN: | PARTS... |
