Dual-port USB Smart Charge Module

Mixed Media - dual-port usb smart charge module

Molex USB smart-charge modules lead the market by combining automotive-grade durability and off-the-shelf availability through distribution.

Typical applications

  • Automotive:
    • Cars
    • Pickup trucks
    • SUVs
  • Commercial Vehicles:
    • Construction equipment
    • Farm equipment
    • Trains
    • Airplanes

Long Copy

Key features

  • USB Battery Charging Specification BC1.2 compliant; YD/T 1591-2009 (China Telecom Specification); Apple MFI compliant; 1.2V Mode
  • Over voltage, reverse battery and over current protection; ESD and short circuit protection; optional tethered dust caps
  • Automotive-grade USB; Type A on the front; 10K cycle life; Molex Mini50 on the rear
  • 2.4A output current; Battery Operating Voltage: 9 to 16V; Operating temperature: -40°C to 85°C
  • Easy-to-read lettering and display; Halo Lighting (Light Pipe); Cosmetic Molding and Pad-Printed Icon; Panel Thickness: 2.5 to 3.5mm"

Block diagram

Molex Dual-port USB Smart Charge Module

Long Copy_documents

More information

Datasheet
USB smart charge modules datasheet (English)
