Murata OCP HPR 33kW Power Shelf MWOCES-191-P-D

MWOCES-191-P-D is a 33.0kW, 19” 1RU power shelf that provides a delivery system for up to six 67mm, 1U Power Supplies (PSU), and one Remote Management Unit (MWOC-RMU3).

This product is installable in a 19-inch rack. Additionally, it is intended to support 50.0V power distribution architectures in OCP ORV3 HPR systems.Two AC input connectors accommodate either three-phase four-wire delta (without neutral) or three-phase five-wire wye (with neutral) configurations for added flexibility. Each input is configured to power a group of three power supply module slots. DC output connection is provided by pluggable bus bars.

Features

• Supports OCP systems
• 1RU height
• 448(W) x809(L) x 44.4(H) mm
• 33kW total output power (N+0)
• Accommodates up to six PSU modules and one RMU
• 50.0V output
• PSU & RMU are hot-swappable
• N+1 / N+N Redundancy
• Busbar-connector temperature sensor capability
• 2-year warranty

Application

Data centers and AI servers

Key Components
