7-188275-6
PCB Receptacle, Board-to-Board, 1.27 mm, 2 Rows, 6 Contacts, Surface Mount Straight, Micro-MaTch
Click image to enlarge
Manufacturer:TE Connectivity
Product Category:
Connectors, PC Board Connectors, Board to Board Connectors
Avnet Manufacturer Part #: 7-188275-6
Secondary Manufacturer Part#: 7-188275-6
-
RoHS 10 Compliant -
Tariff Charges
The Micro-MaTch SMD Female-on-Board connectors from TE Connectivity are designed for standard reflow and infrared solder processes (FULL SMD). Polarization is accomplished by housing therefore no polarization holes in PC board are required. The contact is designed with an additional spring to compensate for differences in thermal expansion between housing and PCB. Due to this feature, tension on solder joints is prevented.
- Tin-plated contact design
- One of the smallest systems available at 1.27mm
- Guaranteed minimum contact force of 2N
- Fretting corrosion proof thanks to additional positioning spring member
- Fully plated contacts - No bare edges and no migration of corrosion products
- Contacts fully protected by polyester housings, except for side-entry female board connector
- Full range of application tooling from hand tool to fully automated equipment
Technical Attributes
Find Similar Parts
| Description | Value | |
|---|---|---|
| Polyamide 46 | ||
| Straight | ||
| Socket | ||
| Phosphor Bronze | ||
| Tin | ||
| Receptacle | ||
| Red | ||
| Tin Over Nickel | ||
| 260 | ||
| 1.5 A | ||
| Surface Mount | ||
| 6 | ||
| 2 | ||
| -40 to 105 °C | ||
| 2.5400 mm | ||
| 7 mm | ||
| 9.7 x 7 x 5.3 mm mm | ||
| 5.3 mm | ||
| 9.7 mm | ||
| 188275 | ||
| Solder | ||
| Socket Strip |
ECCN / UNSPSC / COO
| Description | Value |
|---|---|
| Country of Origin: | null |
| ECCN: | EAR99 |
| HTSN: | PARTS... |
| Schedule B: | PARTS... |
