56050C
Current Transformer 1:50 500VDC 0.133Ohm/0.199Ohm Prim. DCR 10000mA Through Hole
Click image to enlarge
Manufacturer:Murata
Product Category:
Transformers, Current Transformers
Avnet Manufacturer Part #: 56050C
Secondary Manufacturer Part#: 56050C
-
RoHS 10 Compliant -
Tariff Charges
The 56050C is a 10A Current Sensing Transformer, designed to monitor AC currents. This can be used for high frequency current sensing, for example in switched-mode power supplies, motor control and electronic lighting ballasts.
- 20 to 200kHz Frequency Range
- Centre Tapped Variants are Available
- 300°C for 10s Peak Wave Solder Temperature
Technical Attributes
Find Similar Parts
| Description | Value | |
|---|---|---|
| Tin | ||
| Pin | ||
| Through Hole | ||
| 20, 200 kHz | ||
| -40 to 85 °C | ||
| SIP | ||
| 10000 mA | ||
| 5 mH | ||
| 16.79 x 8.89 x 20.19 mm | ||
| Current Sense Transformer | ||
| 1:50 |
ECCN / UNSPSC / COO
| Description | Value |
|---|---|
| Country of Origin: | null |
| ECCN: | EAR99 |
| HTSN: | 8504314035 |
| Schedule B: | 8504314035 |
Factory Lead Time:
