89110-0101
Conn IDC Connector SKT 10 POS 2.54mm IDT RA Cable Mount
Click image to enlarge
Manufacturer:3M
Product Category:
Connectors, PC Board, PCB Receptacles
Avnet Manufacturer Part #: 89110-0101
Secondary Manufacturer Part#: 89110-0101
-
RoHS 10 Compliant -
Tariff Charges
The 89110-0101 is a 10-way 0.100 x 0.100-inch IDC Ribbon Cable Socket for 0.050-inch pitch cable, with gold-plated phosphor bronze contacts and IDC/IDT termination. This 891 series socket is glass filled polyester (PBT) insulated, preassembled, packaging on swords for easy loading of manual and semi-automatic assembly equipment. Double-recessed cover for cable terminating from either side virtually eliminating the need for single-recessed cover connectors, military polarization with centerbump and no strain relief.
- Grey colour
- Bumps are designed to prevent premature latch locking during shipment
- UL94V-0 Flammability rating
- 1 x 10?O at 500VDC Insulation resistance
- -55 to 105°C Temperature rating
Technical Attributes
Find Similar Parts
| Description | Value | |
|---|---|---|
| PBT (Polybutylene Terephthalate) | ||
| Right Angle | ||
| Gold | ||
| 2 | ||
| 2.54 mm |
ECCN / UNSPSC / COO
| Description | Value |
|---|---|
| Country of Origin: | null |
| ECCN: | EAR99 |
| HTSN: | PARTS... |
| Schedule B: | PARTS... |
Factory Lead Time:
