Manufacturer:
Vishay
20109D4X103M5E
CS20109D4X103M5 E e1
Avnet Manufacturer Part #:
20109D4X103M5E
RoHS 10 Exempt
CS20109D4X103M5 E e1
Key Features
- Isolated and bussed schematics available
- X7R and C0G capacitors available
- Multiple isolated capacitors
- Multiple capacitors, common ground
- Custom design capability
- “D” 0.300" (7.62 mm) package height (maximum)
- Compliant to RoHS directive 2002/95/EC
- Halogen-free according to IEC 61249-2-21 definition
Technical Attributes
Find Similar Parts|
|
Description | Value |
|---|---|---|
|
|
Product Length | 22.86 mm |
|
|
Operating Temperature Max | 125 °C |
|
|
Capacitor Mounting | Through Hole |
|
|
Number of Capacitors | 7 |
|
|
Operating Temperature Min | -55 °C |
|
|
Capacitor Terminals | PC Pin |
|
|
Product Width | 22.86 x 3.43 x 7.62 |
|
|
Capacitance | 0.01 uF |
|
|
Voltage(DC) | 50 V |
ECCN / UNSPSC / COO
| Description | Value |
|---|---|
| ECCN: | EAR99 |
| SCHEDULE B: | 8532250080 |
| HTSN: | 8532250080 |
