Manufacturer:
TE Connectivity
3-1415001-2
Electromechanical Relay SPST-NO 70A 12VDC 90Ohm Through Hole
Avnet Manufacturer Part #:
3-1415001-2
Secondary Manufacturer Part #: V23134J0052X511-EV-CBOX
RoHS 10 Compliant
Electromechanical Relay SPST-NO 70A 12VDC 90Ohm Through Hole
Key Features
- Pin assignment similar to ISO 7588 part 1
- Customized versions on request
- 24VDC versions with contact gap >0.8mm
- Integrated components (e.g. resistor, diode)
- Customized marking/color
- Special covers (e.g. notches, release features, brackets)
Technical Attributes
Find Similar Parts|
|
Description | Value |
|---|---|---|
|
|
Minimum Dropout Voltage | 1.6 Vdc |
|
|
Product Length | 26.2 mm |
|
|
Relay Construction | Non-Latching |
|
|
Mounting | Through Hole |
|
|
Operate Time | 7 ms |
|
|
Coil Resistance | 90 Ohm |
|
|
Contact Arrangement | SPST-NO |
|
|
Max Processing Temp | 260 |
|
|
Contact Material | Silver |
|
|
Termination Method | PC Pins |
|
|
Pin Count | 8 |
|
|
Product Dimensions | 26.2(Max) x 26.2(Max) x 25.2(Max) |
|
|
Operating Temperature | -40 to 125 °C |
ECCN / UNSPSC / COO
| Description | Value |
|---|---|
| ECCN: | EAR99 |
| SCHEDULE B: | 8536410005 |
| HTSN: | 8536410060 |
