Manufacturer:
TE Connectivity
2-5747706-0
D Sub Connector, DB9, Standard, Receptacle, AMPLIMITE HD-20, 9 Contacts, DE, Solder
Avnet Manufacturer Part #:
2-5747706-0
RoHS 10 Exempt
The 2-5747706-0 is a 9-way 2-row front metal-shell D-sub Receptacle with gold-plated phosphor bronze contacts and retention 4-40 brass inserts. The Amplimite HD-20 series straight posted receptacle comes with black thermoplastic housing, tin-plated carbon steel shell and bright tin-plated solder tail. All receptacles are preloaded with size 20 DF posted socket contacts. Connectors are intermateable with any size 20 subminiature D connectors dimensionally complying with MIL-C-24308.
Key Features
- UL94V-0 Flammability rating
- Vertical PCB mounting orientation
Technical Attributes
Find Similar Parts|
|
Description | Value |
|---|---|---|
|
|
Contact Plating | Gold Over Nickel |
|
|
Mounting | Through Hole |
|
|
Contact Material | Phosphor Bronze |
|
|
Termination Method | Solder |
|
|
Operating Temperature | -55 to 105 °C |
|
|
Pitch | 2.7400 mm |
|
|
Product Dimensions | 30.81 x 12.54 x 12.16 mm |
|
|
Gender | SKT |
|
|
Lead Finish | Bright Tin |
|
|
Number of Ports | 1 |
|
|
Type | D-Subminiature |
|
|
Base/Housing Material | Thermoplastic |
|
|
Number of Contacts | 9 POS |
|
|
Number of Terminals | 9 |
|
|
Body Orientation | Straight |
|
|
Product Length | 30.81 mm |
|
|
Max Processing Temp | 240|260|265 |
ECCN / UNSPSC / COO
| Description | Value |
|---|---|
| ECCN: | EAR99 |
| SCHEDULE B: | PARTS... |
| HTSN: | PARTS... |
