XMC SC power controllers
Addresses the real-time control needs of wireless power systems
The XMC SC family devices are members of the XMC1000 Family of microcontrollers based on the ARM Cortex-M0 processor core. The XMC SC series addresses the real-time control needs of wireless power systems.
The XMC6521SC-Q040X is a Qi single coil 15W inductive MP-A11 desktop transmitter.
Target applications
- Wireless charging
Features
- Four USIC channels, usable as
- UART (115.2 kb/s)
- IIC (up to 400 kb/s)
- 32-bit ARM Cortex-M0 CPU Core
- MATH coprocessor
- SRAM (with parity)
- Flash (with ECC)
- 3.3 V or 5 V supply with power on reset and brownout detector
- External crystal oscillator support (8 to 20 MHz)
- Window watchdog
- Real time clock module
- Pseudo random number generator
- On-chip clock monitor
- A/D converters for voltage and current sensing
- Temperature Sensor
- 2 PWM channels for full bridge coil driver
- 1 PWM channel for step-up or step-down bridge supply control
- 3.3 V or 5 V capable
- Secure bootloader
- VQFN-40 (5x5 mm2)
Key components
- XMC6521SC-Q040X AA
- BSZ097N04LS
- IRS2301S
- SLS32AIA020A2USON10XTMA1
Benefits
Infineon offers a broad portfolio of efficient, high quality products and solutions to serve the key requirements of the dominant market standards: inductive (Qi (WPC)) and resonant (AirFuel). Whether you charge a smartphone (e.g. at home or in the car), a handful of wearables, a power tool, a laptop or a service robot, Infineon’s components and solutions help you overcome a wide
Block diagram
