MAL225650223E3
Electrolytic Capacitor, 22000 uF, 35 V, ± 20%, Snap-In, 2000 hours @ 105°C, Polar, 256 PMG-SI Series
Click image to enlarge
Manufacturer:Vishay
Product Category:
電容器, 鋁電解電容器, 卡入式/螺絲端子鋁電解電容器
Avnet Manufacturer Part #: MAL225650223E3
Secondary Manufacturer Part#: MAL225650223E3
-
RoHS 10 Compliant -
Tariff Charges
256 PMG-SI is a power miniaturized general purpose aluminium electrolytic capacitor. Typical applications include industrial, standard and switched mode power supplies, audio systems, DC/DC converters, telecom and smoothing and filtering.
- Useful life: 2000h at +105°C, 5000h at +85°C
- Polarized aluminium electrolytic capacitors, non-solid electrolyte
- Pressure relief on the top of the aluminium case
- PET insulation sleeve
- Climatic category in accordance with IEC 60068
- Category temperature range -40°C to +105°C
Technical Attributes
Find Similar Parts
| Description | Value | |
|---|---|---|
| 22000 uF | ||
| ± 20% | ||
| Snap-In | ||
| 0.013 Ohm | ||
| 10 mm | ||
| 2000 hours @ 105°C | ||
| 105 °C | ||
| -40 °C | ||
| Polar | ||
| 35 mm | ||
| 40 mm | ||
| 4.69 A | ||
| 35 V |
ECCN / UNSPSC / COO
| Description | Value |
|---|---|
| Country of Origin: | null |
| ECCN: | EAR99 |
| HTSN: | 8532220020 |
| Schedule B: | 8532220020 |
Factory Lead Time:
