IHLP3232DZER2R2M11
Power Inductor (SMD), 2.2 µH, 14.5 A, Shielded, 10.2 A, IHLP-3232DZ-11 Series
Click image to enlarge
Manufacturer:Vishay
Product Category:
Inductors, Power Inductors, SMD Power Inductors
Avnet Manufacturer Part #: IHLP3232DZER2R2M11
Secondary Manufacturer Part#: IHLP3232DZER2R2M11
-
RoHS 10 Compliant -
Tariff Charges
IHLP3232DZER2R2M11 is an IHLP® low DCR series commercial inductor. Typical applications include PDA / notebook / desktop / server applications, high current POL converters, low profile, high current power supplies, battery powered devices, DC/DC converters in distributed power systems, DC/DC converter for Field Programmable Gate Array (FPGA).
- 2.2µH inductance and ±20% tolerance
- 25MHz self resonant frequency
- Shielded construction
- 14.5A heat rating current DC typ and 10.2A saturation current DC typ
- Operating temperature up to 125°C
- Handles high transient current spikes without saturation
- Ultra low buzz noise, due to composite construction
Technical Attributes
Find Similar Parts
| Description | Value | |
|---|---|---|
| 9410 uOhm | ||
| 2.2 uH | ||
| ±20% | ||
| 3232 | ||
| Shielded | ||
| 4 mm | ||
| 8.64 mm | ||
| IHLP-3232DZ-11 Series | ||
| 8.18 mm | ||
| 14.5 A | ||
| 10.2 A |
ECCN / UNSPSC / COO
| Description | Value |
|---|---|
| Country of Origin: | null |
| ECCN: | EAR99 |
| HTSN: | 8504508000 |
| Schedule B: | 8504500000 |
Factory Lead Time:
