BD8325FVT-ME2

Name: BD8325FVT-ME2
Brand: Rohm
SKU: BD8325FVT-ME2
Availability: InStock

Current Mode PWM Controller 2.45V to 2.85V 1000mA 30-Pin TSSOP Embossed T/R

Click image to enlarge

Manufacturer:Rohm

Product Category: Power Management, Drivers & Controllers, PWM Controllers

Avnet Manufacturer Part #: BD8325FVT-ME2

Secondary Manufacturer Part#: BD8325FVT-ME2

RoHS 10 Compliant
Tariff Charges

Description

BD8325FVT-M is a PWM controller intended for Active clamp, current-mode isolated switching regulator. This controller provides control outputs for driving primary-side MOSFET, and outputs with adjustable delay, which can be used for driving synchronous rectifier MOSFET on the secondary-side. Its maximum input voltage is 20V. External startup regulator can be set at high voltage.

High efficiency/ large current isolated DC/DC (VINmax=100V)
Cellular base station
Industrial power supplies
Car application
10W to 700W SMPS

Technical Attributes

Find Similar Parts

	Description	Value
	Adjustable Output	No
	Duty Cycle Max	70.1 %
	Duty Cycle Min	0 %
	Maximum Duty Cycle	70.1 %
	Mounting	Surface Mount
	No. of Channels	1
	No. of Pins	30
	Number of PWM Outputs	1
	On/Off Pin	Yes
	Operating Supply Voltage	4.0000, 5.5000 V
	Operating Temperature	-40 to 105 °C
	Operating Temperature Max	105 °C
	Operating Temperature Min	-40 °C
	Output Current	1 A
	Output Voltage	2.45 to 2.85 V
	Package	30TSSOP
	Pin Count	30
	Power Supply Controller Type	Secondary Side Controller
	Product Dimensions	10 x 5.6 x 1 mm
	Rad Hard	0
	Supplier Package	TSSOP
	Supply Voltage Max	18 V
	Supply Voltage Min	8 V
	Switching Frequency Max	500 kHz
	Switching Frequency Min	50 kHz
	Topology	Flyback, Forward, Forward
