NKE0305SC
Isolated Through Hole DC/DC Converter, Industrial & ITE, 1 W, 1 Output, Fixed, 5 V, 200 mA, Unregulated, SIP
Click image to enlarge
Manufacturer:Murata
Product Category:
電源, DC/DC 轉換器, 隔離式通孔DC/DC轉換器
Avnet Manufacturer Part #: NKE0305SC
Secondary Manufacturer Part#: NKE0305SC
-
RoHS 10 Compliant -
Tariff Charges
The NKE0305SC is a 1-output board-mount isolated Sub-miniature DC to DC Converter particularly suited to isolating and/or converting DC power rails. The NKE series 1W converter features improved efficiency, lower output ripple through state of the art improved technology. The galvanic isolation allows the device to be configured to provide an isolated negative rail in systems where only positive rails exist.
- 3kVDC Isolation
- Increased power density to 2.09W/cm³
- Footprint at 0.69cm²
- Industry standard pinout
- Internal SMD construction
- Fully encapsulated with toroidal magnetics
- MTTF up to 2.4million hours
- No electrolytic or tantalum capacitors
- -40 to +85°C Wide operating temperature range
Technical Attributes
Find Similar Parts
| Description | Value | |
|---|---|---|
| Fixed | ||
| SIP | ||
| 3.63 V | ||
| 2.97 V | ||
| 3.3 V | ||
| 3 kV | ||
| 1 | ||
| -40 to 85 to 85 °C | ||
| 200 mA | ||
| 200 mA | ||
| 1 W | ||
| Unregulated | ||
| 5 V | ||
| 5 V | ||
| Industrial & ITE | ||
| 11.53 mm | ||
| 11.53 x 6.1 x 7.46 mm | ||
| 7.46 mm | ||
| 6.1 mm |
ECCN / UNSPSC / COO
| Description | Value |
|---|---|
| Country of Origin: | null |
| ECCN: | EAR99 |
| HTSN: | 8504409510 |
| Schedule B: | 8504409510 |
