EL817S1(C)(TU)-F

Optocoupler 1-CH DC-OUT 5000Vrms 4-Pin DIP SMD T/R

Click image to enlarge

EL817S1(C)(TU)-F

Manufacturer:Everlight

Product Category: Filters, Feedthrough Capacitors

Avnet Manufacturer Part #: EL817S1(C)(TU)-F

Datasheet

RoHS 10 Compliant
Tariff Charges

Description

Current transfer ratio (CTR: 50~600% at IF =5mA, VCE =5V)
High isolation voltage between input and output (Viso=5000 V rms )
Creepage distance >7.62 mm
Operating temperature up to +110°C
Compact small outline package
Pb free and RoHS compliant

Technical Attributes

Find Similar Parts

	Description	Value
	Capacitance	null
	Capacitance Tolerance	null
	Capacitor Mounting	null
	Current Rating	null
	DC Resistance Max	null
	Dielectric Characteristic	null
	Forward Voltage	1.2 MV
	Input Current	60 MA
	Insulation Resistance	null
	Operating Temperature Max	null
	Operating Temperature Min	null
	Output Type	DC
	Power Dissipation	200 mW
	Product Range	null
	Reverse Voltage	6 V
	Voltage Rating	null

ECCN / UNSPSC / COO

Description	Value
Country of Origin:	null
ECCN:	EAR99
HTSN:	null
Schedule B:	null

In Stock : 0

Additional inventory

Factory Lead Time: 16 Weeks

Price for: Each

Quantity:

Min:20000 Mult:2000

Need More?

USD $:

$ 0.00000

0+

$0.00000

SubTotal:

$0.00
